Merge branch 'main' into CURA-12400_improve-open-source-referencing
This commit is contained in:
Erwan MATHIEU
GitHub
commit
190466ab6a
52 changed files with 1932 additions and 32 deletions
README.md
cura/Settings
licenses_thirdparty
plugins/PostProcessingPlugin/scripts
resources
definitions
fdmprinter.def.jsonultimaker_method.def.jsonultimaker_replicator_plus.def.jsonultimaker_s8.def.jsonultimaker_sketch.def.jsonultimaker_sketch_sprint.def.json
extruders
images
Ultimaker2PlusConnectbackplate.pngUltimakerFactor4Backplate.pngUltimakerS3backplate.pngUltimakerS5backplate.pngUltimakerS7backplate.png
intent
ultimaker_methodx
um_methodx_1c_um-pc-abs-175_0.2mm_solid.inst.cfgum_methodx_1c_um-pc-abs-fr-175_0.2mm_solid.inst.cfgum_methodx_1xa_um-pc-abs-175_0.2mm_solid.inst.cfgum_methodx_1xa_um-pc-abs-fr-175_0.2mm_solid.inst.cfgum_methodx_labs_um-pc-abs-175_0.2mm_solid.inst.cfgum_methodx_labs_um-pc-abs-fr-175_0.2mm_solid.inst.cfg
ultimaker_methodxl
um_methodxl_1c_um-pc-abs-175_0.2mm_solid.inst.cfgum_methodxl_1c_um-pc-abs-fr-175_0.2mm_solid.inst.cfgum_methodxl_1xa_um-pc-abs-175_0.2mm_solid.inst.cfgum_methodxl_1xa_um-pc-abs-fr-175_0.2mm_solid.inst.cfgum_methodxl_labs_um-pc-abs-175_0.2mm_solid.inst.cfgum_methodxl_labs_um-pc-abs-fr-175_0.2mm_solid.inst.cfg
ultimaker_replicator_plus
meshes
qml/Menus/ConfigurationMenu
quality
ultimaker_methodx
um_methodx_1c_um-pc-abs-175_0.2mm.inst.cfgum_methodx_1c_um-pc-abs-fr-175_0.2mm.inst.cfgum_methodx_1xa_um-pc-abs-175_0.2mm.inst.cfgum_methodx_1xa_um-pc-abs-fr-175_0.2mm.inst.cfgum_methodx_labs_um-pc-abs-175_0.2mm.inst.cfgum_methodx_labs_um-pc-abs-fr-175_0.2mm.inst.cfg
ultimaker_methodxl
um_methodxl_1c_um-pc-abs-175_0.2mm.inst.cfgum_methodxl_1c_um-pc-abs-fr-175_0.2mm.inst.cfgum_methodxl_1xa_um-pc-abs-175_0.2mm.inst.cfgum_methodxl_1xa_um-pc-abs-fr-175_0.2mm.inst.cfgum_methodxl_labs_um-pc-abs-175_0.2mm.inst.cfgum_methodxl_labs_um-pc-abs-fr-175_0.2mm.inst.cfg
ultimaker_replicator_plus
um_replicator_b_smartextruder_plus_experimental_um-pla-175_0.2mm.inst.cfgum_replicator_b_smartextruder_plus_experimental_um-tough-pla-175_0.2mm.inst.cfgum_replicator_b_smartextruder_plus_tough_um-tough-pla-175_0.2mm.inst.cfgum_replicator_b_smartextruder_plus_um-pla-175_0.2mm.inst.cfgum_replicator_plus_global_Draft_Quality.inst.cfg
texts
variants
|
|
@ -39,6 +39,8 @@
|
|||
[![Button Settings]][Settings]
|
||||
[![Button Localize]][Localize]
|
||||
|
||||
[![Button Libraries]][Libraries]
|
||||
|
||||
<br>
|
||||
<br>
|
||||
|
||||
|
|
@ -75,6 +77,7 @@
|
|||
[Report]: docs/Report.md
|
||||
[Logo]: resources/images/cura-icon.png
|
||||
[#]: #
|
||||
[Libraries]: https://github.com/Ultimaker/Cura/blob/main/licenses_thirdparty
|
||||
|
||||
|
||||
<!---------------------------------[ Badges ]---------------------------------->
|
||||
|
|
@ -90,6 +93,7 @@
|
|||
[Badge Downloads]: https://img.shields.io/github/downloads-pre/Ultimaker/Cura/latest/total?style=for-the-badge
|
||||
|
||||
|
||||
|
||||
<!---------------------------------[ Buttons ]--------------------------------->
|
||||
|
||||
[Button Localize]: https://img.shields.io/badge/Help_Localize-e2467d?style=for-the-badge&logoColor=white&logo=GoogleTranslate
|
||||
|
|
@ -98,5 +102,6 @@
|
|||
[Button Building]: https://img.shields.io/badge/Building_Cura-blue?style=for-the-badge&logoColor=white&logo=GitBook
|
||||
[Button Plugins]: https://img.shields.io/badge/Plugin_Usage-569A31?style=for-the-badge&logoColor=white&logo=ROS
|
||||
[Button Report]: https://img.shields.io/badge/Report_Issues-C9284D?style=for-the-badge&logoColor=white&logo=Cliqz
|
||||
[Button Libraries]: https://img.shields.io/badge/third--party_libraries-b928c9?style=for-the-badge
|
||||
|
||||
|
||||
|
|
|
|||
|
|
@ -257,6 +257,7 @@ class ExtruderManager(QObject):
|
|||
limit_to_extruder_feature_list = ["wall_0_extruder_nr",
|
||||
"wall_x_extruder_nr",
|
||||
"roofing_extruder_nr",
|
||||
"flooring_extruder_nr",
|
||||
"top_bottom_extruder_nr",
|
||||
"infill_extruder_nr",
|
||||
]
|
||||
|
|
|
|||
24
licenses_thirdparty/qt.md
vendored
Normal file
24
licenses_thirdparty/qt.md
vendored
Normal file
|
|
@ -0,0 +1,24 @@
|
|||
Sources for the Qt modules that Cura uses (links within UltiMaker repositories):
|
||||
|
||||
- qtbase: https://github.com/Ultimaker/qtbase
|
||||
- qtdeclarative: https://github.com/Ultimaker/qtdeclarative
|
||||
- qtsvg: https://github.com/Ultimaker/qtsvg
|
||||
- qtshadertools: https://github.com/Ultimaker/qtshadertools
|
||||
- qtimageformats: https://github.com/Ultimaker/qtimageformats
|
||||
|
||||
Sources for Qt modules that Cura doesn't use (and thus aren't necessary for building or running any part of Cura), but that may be shipped along the product anyway due to our build-process (links to off-site):
|
||||
|
||||
- qtsensors: https://github.com/qt/qtsensors
|
||||
- qtmultimedia: https://github.com/qt/qtmultimedia
|
||||
- qtpositioning: https://github.com/qt/qtpositioning
|
||||
- qtremoteobjects: https://github.com/qt/qtremoteobjects
|
||||
- qttexttospeech: https://github.com/qt/qtspeech
|
||||
- qtwebchannel: https://github.com/qt/qtwebchannel
|
||||
- qtwebsockets: https://github.com/qt/qtwebsockets
|
||||
- qtserialport: https://github.com/qt/qtserialport
|
||||
- qt (5) (linux): https://github.com/qt/qt5
|
||||
|
||||
Versions of Qt used in Cura (from 5.9.1 onwards):
|
||||
|
||||
- 5.9.x: Qt 6.6.0
|
||||
- 5.10.x: Qt 6.6.0
|
||||
|
|
@ -1,20 +1,20 @@
|
|||
# Copyright (c) 2017 Ghostkeeper
|
||||
# The PostProcessingPlugin is released under the terms of the LGPLv3 or higher.
|
||||
# Altered by GregValiant (Greg Foresi) February, 2025.
|
||||
# Added option for "first instance only"
|
||||
# Added option for a layer search with a Start Layer and an End layer.
|
||||
# Added 'Ignore StartUp G-code' and 'Ignore Ending G-code' options
|
||||
|
||||
import re # To perform the search and replace.
|
||||
|
||||
import re
|
||||
from ..Script import Script
|
||||
|
||||
from UM.Application import Application
|
||||
|
||||
class SearchAndReplace(Script):
|
||||
"""Performs a search-and-replace on all g-code.
|
||||
|
||||
Due to technical limitations, the search can't cross the border between
|
||||
layers.
|
||||
"""Performs a search-and-replace on the g-code.
|
||||
"""
|
||||
|
||||
def getSettingDataString(self):
|
||||
return """{
|
||||
return r"""{
|
||||
"name": "Search and Replace",
|
||||
"key": "SearchAndReplace",
|
||||
"metadata": {},
|
||||
|
|
@ -23,37 +23,145 @@ class SearchAndReplace(Script):
|
|||
{
|
||||
"search":
|
||||
{
|
||||
"label": "Search",
|
||||
"description": "All occurrences of this text will get replaced by the replacement text.",
|
||||
"label": "Search for:",
|
||||
"description": "All occurrences of this text (within the search range) will be replaced by the 'Replace with' string. The search string is 'Case Sensitive' and 'Layer' is not the same as 'layer'.",
|
||||
"type": "str",
|
||||
"default_value": ""
|
||||
},
|
||||
"replace":
|
||||
{
|
||||
"label": "Replace",
|
||||
"description": "The search text will get replaced by this text.",
|
||||
"label": "Replace with:",
|
||||
"description": "The 'Search For' text will get replaced by this text. For MultiLine insertions use the newline character '\\n' as the delimiter. If your Search term ends with a '\\n' remember to add '\\n' to the end of this Replace term.",
|
||||
"type": "str",
|
||||
"default_value": ""
|
||||
},
|
||||
"is_regex":
|
||||
{
|
||||
"label": "Use Regular Expressions",
|
||||
"description": "When enabled, the search text will be interpreted as a regular expression.",
|
||||
"description": "When disabled the search string is treated as a simple text string. When enabled, the search text will be interpreted as a Python regular expression.",
|
||||
"type": "bool",
|
||||
"default_value": false
|
||||
},
|
||||
"enable_layer_search":
|
||||
{
|
||||
"label": "Enable search within a Layer Range:",
|
||||
"description": "When enabled, You can choose a Start and End layer for the search. When 'Layer Search' is enabled the StartUp and Ending gcodes are always ignored.",
|
||||
"type": "bool",
|
||||
"default_value": false,
|
||||
"enabled": true
|
||||
},
|
||||
"search_start":
|
||||
{
|
||||
"label": "Start S&R at Layer:",
|
||||
"description": "Use the Cura Preview layer numbering.",
|
||||
"type": "int",
|
||||
"default_value": 1,
|
||||
"minimum_value": 1,
|
||||
"enabled": "enable_layer_search"
|
||||
},
|
||||
"search_end":
|
||||
{
|
||||
"label": "Stop S&R at end of Layer:",
|
||||
"description": "Use the Cura Preview layer numbering. The replacements will conclude at the end of this layer. If the End Layer is equal to the Start Layer then only that single layer is searched.",
|
||||
"type": "int",
|
||||
"default_value": 2,
|
||||
"minimum_value": 1,
|
||||
"enabled": "enable_layer_search"
|
||||
},
|
||||
"first_instance_only":
|
||||
{
|
||||
"label": "Replace first instance only:",
|
||||
"description": "When enabled only the first instance is replaced.",
|
||||
"type": "bool",
|
||||
"default_value": false,
|
||||
"enabled": true
|
||||
},
|
||||
"ignore_start":
|
||||
{
|
||||
"label": "Ignore StartUp G-code:",
|
||||
"description": "When enabled the StartUp Gcode is unaffected. The StartUp Gcode is everything from ';generated with Cura...' to ';LAYER_COUNT:' inclusive.",
|
||||
"type": "bool",
|
||||
"default_value": true,
|
||||
"enabled": "not enable_layer_search"
|
||||
},
|
||||
"ignore_end":
|
||||
{
|
||||
"label": "Ignore Ending G-code:",
|
||||
"description": "When enabled the Ending Gcode is unaffected.",
|
||||
"type": "bool",
|
||||
"default_value": true,
|
||||
"enabled": "not enable_layer_search"
|
||||
}
|
||||
}
|
||||
}"""
|
||||
|
||||
def execute(self, data):
|
||||
global_stack = Application.getInstance().getGlobalContainerStack()
|
||||
extruder = global_stack.extruderList
|
||||
retract_enabled = bool(extruder[0].getProperty("retraction_enable", "value"))
|
||||
search_string = self.getSettingValueByKey("search")
|
||||
if not self.getSettingValueByKey("is_regex"):
|
||||
search_string = re.escape(search_string) #Need to search for the actual string, not as a regex.
|
||||
search_regex = re.compile(search_string)
|
||||
|
||||
replace_string = self.getSettingValueByKey("replace")
|
||||
is_regex = self.getSettingValueByKey("is_regex")
|
||||
enable_layer_search = self.getSettingValueByKey("enable_layer_search")
|
||||
start_layer = self.getSettingValueByKey("search_start")
|
||||
end_layer = self.getSettingValueByKey("search_end")
|
||||
ignore_start = self.getSettingValueByKey("ignore_start")
|
||||
ignore_end = self.getSettingValueByKey("ignore_end")
|
||||
if enable_layer_search:
|
||||
ignore_start = True
|
||||
ignore_end = True
|
||||
first_instance_only = bool(self.getSettingValueByKey("first_instance_only"))
|
||||
|
||||
for layer_number, layer in enumerate(data):
|
||||
data[layer_number] = re.sub(search_regex, replace_string, layer) #Replace all.
|
||||
# Account for missing layer numbers when a raft is used
|
||||
start_index = 1
|
||||
end_index = len(data) - 1
|
||||
data_list = [0,1]
|
||||
layer_list = [-1,0]
|
||||
lay_num = 1
|
||||
for index, layer in enumerate(data):
|
||||
if re.search(r";LAYER:(-?\d+)", layer):
|
||||
data_list.append(index)
|
||||
layer_list.append(lay_num)
|
||||
lay_num += 1
|
||||
|
||||
return data
|
||||
# Get the start and end indexes within the data
|
||||
if not enable_layer_search:
|
||||
if ignore_start:
|
||||
start_index = 2
|
||||
else:
|
||||
start_index = 1
|
||||
|
||||
if ignore_end:
|
||||
end_index = data_list[len(data_list) - 1]
|
||||
else:
|
||||
# Account for the extra data item when retraction is enabled
|
||||
end_index = data_list[len(data_list) - 1] + (2 if retract_enabled else 1)
|
||||
|
||||
elif enable_layer_search:
|
||||
for index, num in enumerate(layer_list):
|
||||
if num == start_layer:
|
||||
start_index = data_list[index]
|
||||
if num == end_layer:
|
||||
end_index = data_list[index]
|
||||
|
||||
# Make replacements
|
||||
replace_one = False
|
||||
if not is_regex:
|
||||
search_string = re.escape(search_string)
|
||||
search_regex = re.compile(search_string)
|
||||
for num in range(start_index, end_index + 1, 1):
|
||||
layer = data[num]
|
||||
# First_instance only
|
||||
if first_instance_only:
|
||||
if re.search(search_regex, layer) and replace_one == False:
|
||||
data[num] = re.sub(search_regex, replace_string, data[num], 1)
|
||||
replace_one = True
|
||||
break
|
||||
# All instances
|
||||
else:
|
||||
if end_index > start_index:
|
||||
data[num] = re.sub(search_regex, replace_string, layer)
|
||||
elif end_index == start_index:
|
||||
layer = data[start_index]
|
||||
data[start_index] = re.sub(search_regex, replace_string, layer)
|
||||
return data
|
||||
|
|
|
|||
|
|
@ -1545,6 +1545,90 @@
|
|||
}
|
||||
}
|
||||
},
|
||||
"flooring_extruder_nr":
|
||||
{
|
||||
"label": "Bottom Surface Skin Extruder",
|
||||
"description": "The extruder train used for printing the bottom most skin. This is used in multi-extrusion.",
|
||||
"type": "optional_extruder",
|
||||
"default_value": "-1",
|
||||
"value": "top_bottom_extruder_nr",
|
||||
"settable_per_mesh": false,
|
||||
"settable_per_extruder": false,
|
||||
"settable_per_meshgroup": true,
|
||||
"settable_globally": true,
|
||||
"enabled": "extruders_enabled_count > 1 and max(extruderValues('flooring_layer_count')) > 0 and max(extruderValues('bottom_layers')) > 0"
|
||||
},
|
||||
"flooring_layer_count":
|
||||
{
|
||||
"label": "Bottom Surface Skin Layers",
|
||||
"description": "The number of bottom most skin layers. Usually only one bottom most layer is sufficient to generate higher quality bottom surfaces.",
|
||||
"default_value": 0,
|
||||
"minimum_value": "0",
|
||||
"maximum_value_warning": "bottom_layers - 1",
|
||||
"type": "int",
|
||||
"maximum_value": "999999",
|
||||
"value": "0",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true,
|
||||
"enabled": "bottom_layers > 0",
|
||||
"children":
|
||||
{
|
||||
"flooring_line_width":
|
||||
{
|
||||
"label": "Bottom Surface Skin Line Width",
|
||||
"description": "Width of a single line of the areas at the bottom of the print.",
|
||||
"unit": "mm",
|
||||
"minimum_value": "0.001",
|
||||
"minimum_value_warning": "0.1 + 0.4 * machine_nozzle_size",
|
||||
"maximum_value_warning": "2 * machine_nozzle_size",
|
||||
"default_value": 0.4,
|
||||
"type": "float",
|
||||
"value": "skin_line_width",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true,
|
||||
"enabled": "flooring_layer_count > 0 and bottom_layers > 0"
|
||||
},
|
||||
"flooring_pattern":
|
||||
{
|
||||
"label": "Bottom Surface Skin Pattern",
|
||||
"description": "The pattern of the bottom most layers.",
|
||||
"type": "enum",
|
||||
"options":
|
||||
{
|
||||
"lines": "Lines",
|
||||
"concentric": "Concentric",
|
||||
"zigzag": "Zig Zag"
|
||||
},
|
||||
"default_value": "lines",
|
||||
"value": "top_bottom_pattern",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true,
|
||||
"enabled": "flooring_layer_count > 0 and bottom_layers > 0"
|
||||
},
|
||||
"flooring_monotonic":
|
||||
{
|
||||
"label": "Monotonic Bottom Surface Order",
|
||||
"description": "Print bottom surface lines in an ordering that causes them to always overlap with adjacent lines in a single direction. This takes slightly more time to print, but makes flat surfaces look more consistent.",
|
||||
"type": "bool",
|
||||
"value": true,
|
||||
"default_value": true,
|
||||
"enabled": "flooring_layer_count > 0 and bottom_layers > 0 and flooring_pattern != 'concentric'",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"flooring_angles":
|
||||
{
|
||||
"label": "Bottom Surface Skin Line Directions",
|
||||
"description": "A list of integer line directions to use when the bottom surface skin layers use the lines or zig zag pattern. Elements from the list are used sequentially as the layers progress and when the end of the list is reached, it starts at the beginning again. The list items are separated by commas and the whole list is contained in square brackets. Default is an empty list which means use the traditional default angles (45 and 135 degrees).",
|
||||
"type": "[int]",
|
||||
"default_value": "[ ]",
|
||||
"value": "skin_angles",
|
||||
"enabled": "flooring_pattern != 'concentric' and flooring_layer_count > 0 and bottom_layers > 0",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
}
|
||||
}
|
||||
},
|
||||
"top_bottom_extruder_nr":
|
||||
{
|
||||
"label": "Top/Bottom Extruder",
|
||||
|
|
@ -2953,6 +3037,34 @@
|
|||
"maximum_value_warning": "150",
|
||||
"limit_to_extruder": "wall_x_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"wall_0_material_flow_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Outer Wall Flow",
|
||||
"description": "Flow compensation on the bottom surface outermost wall line.",
|
||||
"unit": "%",
|
||||
"type": "float",
|
||||
"default_value": 100,
|
||||
"value": "wall_0_material_flow",
|
||||
"minimum_value": "0.0001",
|
||||
"minimum_value_warning": "50",
|
||||
"maximum_value_warning": "150",
|
||||
"limit_to_extruder": "wall_0_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"wall_x_material_flow_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Inner Wall(s) Flow",
|
||||
"description": "Flow compensation on bottom surface wall lines for all wall lines except the outermost one.",
|
||||
"unit": "%",
|
||||
"type": "float",
|
||||
"default_value": 100,
|
||||
"value": "wall_x_material_flow",
|
||||
"minimum_value": "0.0001",
|
||||
"minimum_value_warning": "50",
|
||||
"maximum_value_warning": "150",
|
||||
"limit_to_extruder": "wall_x_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
}
|
||||
}
|
||||
},
|
||||
|
|
@ -2986,6 +3098,21 @@
|
|||
"settable_per_mesh": true,
|
||||
"enabled": "roofing_layer_count > 0 and top_layers > 0"
|
||||
},
|
||||
"flooring_material_flow":
|
||||
{
|
||||
"label": "Bottom Surface Skin Flow",
|
||||
"description": "Flow compensation on lines of the areas at the bottom of the print.",
|
||||
"unit": "%",
|
||||
"type": "float",
|
||||
"default_value": 100,
|
||||
"value": "skin_material_flow",
|
||||
"minimum_value": "0.0001",
|
||||
"minimum_value_warning": "50",
|
||||
"maximum_value_warning": "150",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true,
|
||||
"enabled": "flooring_layer_count > 0 and bottom_layers > 0"
|
||||
},
|
||||
"infill_material_flow":
|
||||
{
|
||||
"label": "Infill Flow",
|
||||
|
|
@ -3353,6 +3480,34 @@
|
|||
"value": "speed_wall_x",
|
||||
"limit_to_extruder": "wall_x_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"speed_wall_0_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Outer Wall Speed",
|
||||
"description": "The speed at which the bottom surface outermost wall is printed.",
|
||||
"unit": "mm/s",
|
||||
"type": "float",
|
||||
"minimum_value": "0.1",
|
||||
"maximum_value": "math.sqrt(machine_max_feedrate_x ** 2 + machine_max_feedrate_y ** 2)",
|
||||
"maximum_value_warning": "150",
|
||||
"default_value": 30,
|
||||
"value": "speed_wall_0",
|
||||
"limit_to_extruder": "wall_0_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"speed_wall_x_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Inner Wall Speed",
|
||||
"description": "The speed at which the bottom surface inner walls are printed.",
|
||||
"unit": "mm/s",
|
||||
"type": "float",
|
||||
"minimum_value": "0.1",
|
||||
"maximum_value": "math.sqrt(machine_max_feedrate_x ** 2 + machine_max_feedrate_y ** 2)",
|
||||
"maximum_value_warning": "150",
|
||||
"default_value": 60,
|
||||
"value": "speed_wall_x",
|
||||
"limit_to_extruder": "wall_x_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
}
|
||||
}
|
||||
},
|
||||
|
|
@ -3371,6 +3526,21 @@
|
|||
"settable_per_mesh": true,
|
||||
"enabled": "roofing_layer_count > 0 and top_layers > 0"
|
||||
},
|
||||
"speed_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Skin Speed",
|
||||
"description": "The speed at which bottom surface skin layers are printed.",
|
||||
"unit": "mm/s",
|
||||
"type": "float",
|
||||
"minimum_value": "0.1",
|
||||
"maximum_value": "math.sqrt(machine_max_feedrate_x ** 2 + machine_max_feedrate_y ** 2)",
|
||||
"maximum_value_warning": "150",
|
||||
"default_value": 25,
|
||||
"value": "speed_topbottom",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true,
|
||||
"enabled": "flooring_layer_count > 0 and bottom_layers > 0"
|
||||
},
|
||||
"speed_topbottom":
|
||||
{
|
||||
"label": "Top/Bottom Speed",
|
||||
|
|
@ -3726,6 +3896,36 @@
|
|||
"enabled": "resolveOrValue('acceleration_enabled')",
|
||||
"limit_to_extruder": "wall_x_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"acceleration_wall_0_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Outer Wall Acceleration",
|
||||
"description": "The acceleration with which the bottom surface outermost walls are printed.",
|
||||
"unit": "mm/s\u00b2",
|
||||
"type": "float",
|
||||
"minimum_value": "0.1",
|
||||
"minimum_value_warning": "100",
|
||||
"maximum_value_warning": "10000",
|
||||
"default_value": 3000,
|
||||
"value": "acceleration_wall_0",
|
||||
"enabled": "resolveOrValue('acceleration_enabled')",
|
||||
"limit_to_extruder": "wall_0_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"acceleration_wall_x_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Inner Wall Acceleration",
|
||||
"description": "The acceleration with which the bottom surface inner walls are printed.",
|
||||
"unit": "mm/s\u00b2",
|
||||
"type": "float",
|
||||
"minimum_value": "0.1",
|
||||
"minimum_value_warning": "100",
|
||||
"maximum_value_warning": "10000",
|
||||
"default_value": 3000,
|
||||
"value": "acceleration_wall_x",
|
||||
"enabled": "resolveOrValue('acceleration_enabled')",
|
||||
"limit_to_extruder": "wall_x_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
}
|
||||
}
|
||||
},
|
||||
|
|
@ -3744,6 +3944,21 @@
|
|||
"limit_to_extruder": "roofing_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"acceleration_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Skin Acceleration",
|
||||
"description": "The acceleration with which bottom surface skin layers are printed.",
|
||||
"unit": "mm/s\u00b2",
|
||||
"type": "float",
|
||||
"minimum_value": "0.1",
|
||||
"minimum_value_warning": "100",
|
||||
"maximum_value_warning": "10000",
|
||||
"default_value": 3000,
|
||||
"value": "acceleration_topbottom",
|
||||
"enabled": "resolveOrValue('acceleration_enabled') and flooring_layer_count > 0 and bottom_layers > 0",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"acceleration_topbottom":
|
||||
{
|
||||
"label": "Top/Bottom Acceleration",
|
||||
|
|
@ -4053,6 +4268,34 @@
|
|||
"enabled": "resolveOrValue('jerk_enabled')",
|
||||
"limit_to_extruder": "wall_x_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"jerk_wall_0_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Outer Wall Jerk",
|
||||
"description": "The maximum instantaneous velocity change with which the bottom surface outermost walls are printed.",
|
||||
"unit": "mm/s",
|
||||
"type": "float",
|
||||
"minimum_value": "0",
|
||||
"maximum_value_warning": "50",
|
||||
"default_value": 20,
|
||||
"value": "jerk_wall_0",
|
||||
"enabled": "resolveOrValue('jerk_enabled')",
|
||||
"limit_to_extruder": "wall_0_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"jerk_wall_x_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Inner Wall Jerk",
|
||||
"description": "The maximum instantaneous velocity change with which the bottom surface inner walls are printed.",
|
||||
"unit": "mm/s",
|
||||
"type": "float",
|
||||
"minimum_value": "0",
|
||||
"maximum_value_warning": "50",
|
||||
"default_value": 20,
|
||||
"value": "jerk_wall_x",
|
||||
"enabled": "resolveOrValue('jerk_enabled')",
|
||||
"limit_to_extruder": "wall_x_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
}
|
||||
}
|
||||
},
|
||||
|
|
@ -4070,6 +4313,20 @@
|
|||
"limit_to_extruder": "roofing_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"jerk_flooring":
|
||||
{
|
||||
"label": "Bottom Surface Skin Jerk",
|
||||
"description": "The maximum instantaneous velocity change with which bottom surface skin layers are printed.",
|
||||
"unit": "mm/s",
|
||||
"type": "float",
|
||||
"minimum_value": "0",
|
||||
"maximum_value_warning": "50",
|
||||
"default_value": 20,
|
||||
"value": "jerk_topbottom",
|
||||
"enabled": "resolveOrValue('jerk_enabled') and flooring_layer_count > 0 and bottom_layers > 0",
|
||||
"limit_to_extruder": "flooring_extruder_nr",
|
||||
"settable_per_mesh": true
|
||||
},
|
||||
"jerk_topbottom":
|
||||
{
|
||||
"label": "Top/Bottom Jerk",
|
||||
|
|
|
|||
|
|
@ -59,6 +59,8 @@
|
|||
"zyyx_pro_",
|
||||
"octofiber_",
|
||||
"fiberlogy_",
|
||||
"ultimaker_pc-abs",
|
||||
"ultimaker_pc-abs-fr",
|
||||
"ultimaker_metallic_pla_175"
|
||||
],
|
||||
"has_machine_materials": true,
|
||||
|
|
|
|||
274
resources/definitions/ultimaker_replicator_plus.def.json
Normal file
274
resources/definitions/ultimaker_replicator_plus.def.json
Normal file
|
|
@ -0,0 +1,274 @@
|
|||
{
|
||||
"version": 2,
|
||||
"name": "MakerBot Replicator+",
|
||||
"inherits": "ultimaker",
|
||||
"metadata":
|
||||
{
|
||||
"visible": true,
|
||||
"author": "Ultimaker",
|
||||
"manufacturer": "Ultimaker B.V.",
|
||||
"file_formats": "application/x-makerbot-replicator_plus",
|
||||
"platform": "ultimaker_replicator_plus_platform.3MF",
|
||||
"exclude_materials": [
|
||||
"dsm_",
|
||||
"Essentium_",
|
||||
"imade3d_",
|
||||
"chromatik_",
|
||||
"3D-Fuel_",
|
||||
"bestfilament_",
|
||||
"eazao_",
|
||||
"emotiontech_",
|
||||
"eryone_",
|
||||
"eSUN_",
|
||||
"Extrudr_",
|
||||
"fabtotum_",
|
||||
"fdplast_",
|
||||
"filo3d_",
|
||||
"ultimaker_rapidrinse_175",
|
||||
"goofoo_",
|
||||
"ideagen3D_",
|
||||
"imade3d_",
|
||||
"innofill_",
|
||||
"layer_one_",
|
||||
"leapfrog_",
|
||||
"polyflex_pla",
|
||||
"polymax_pla",
|
||||
"polyplus_pla",
|
||||
"polywood_pla",
|
||||
"redd_",
|
||||
"tizyx_",
|
||||
"verbatim_",
|
||||
"Vertex_",
|
||||
"volumic_",
|
||||
"xyzprinting_",
|
||||
"zyyx_pro_",
|
||||
"octofiber_",
|
||||
"fiberlogy_",
|
||||
"generic_",
|
||||
"ultimaker_asa",
|
||||
"ultimaker_abs",
|
||||
"ultimaker_nylon",
|
||||
"ultimaker_pva",
|
||||
"ultimaker_rapidrinse",
|
||||
"ultimaker_sr30",
|
||||
"ultimaker_petg",
|
||||
"basf_",
|
||||
"jabil_",
|
||||
"polymaker_",
|
||||
"lehvoss",
|
||||
"ultimaker_metallic_pla",
|
||||
"ultimaker_pc-abs"
|
||||
],
|
||||
"has_machine_quality": true,
|
||||
"has_materials": true,
|
||||
"has_variants": true,
|
||||
"machine_extruder_trains": { "0": "ultimaker_replicator_extruder" },
|
||||
"preferred_material": "ultimaker_pla_175",
|
||||
"preferred_quality_type": "draft",
|
||||
"preferred_variant_name": "ultimaker_replicator_smart_extruder_plus",
|
||||
"reference_machine_id": "replicator_b",
|
||||
"supports_network_connection": true,
|
||||
"supports_usb_connection": false,
|
||||
"variants_name": "Extruder",
|
||||
"weight": -1
|
||||
},
|
||||
"overrides":
|
||||
{
|
||||
"acceleration_enabled":
|
||||
{
|
||||
"enabled": false,
|
||||
"value": false
|
||||
},
|
||||
"adhesion_type": { "value": "'raft'" },
|
||||
"brim_width": { "value": "3" },
|
||||
"cool_during_extruder_switch":
|
||||
{
|
||||
"enabled": false,
|
||||
"value": false
|
||||
},
|
||||
"cool_fan_full_at_height": { "value": "layer_height + layer_height_0" },
|
||||
"cool_fan_speed": { "value": 100 },
|
||||
"cool_fan_speed_0": { "value": 0 },
|
||||
"cool_min_layer_time": { "value": 5 },
|
||||
"extruder_prime_pos_abs": { "default_value": true },
|
||||
"fill_outline_gaps": { "value": true },
|
||||
"gantry_height": { "value": "60" },
|
||||
"gradual_support_infill_steps": { "value": 0 },
|
||||
"infill_angles": { "value": "[45,45,45,45,45,135,135,135,135,135]" },
|
||||
"infill_before_walls": { "value": false },
|
||||
"infill_overlap": { "value": 0 },
|
||||
"infill_pattern": { "value": "'zigzag'" },
|
||||
"infill_sparse_density": { "value": 10 },
|
||||
"infill_wipe_dist": { "value": 0 },
|
||||
"initial_layer_line_width_factor":
|
||||
{
|
||||
"maximum_value": 300,
|
||||
"maximum_value_warning": 250,
|
||||
"value": "125 if resolveOrValue('adhesion_type') == 'raft' else 200"
|
||||
},
|
||||
"inset_direction": { "value": "'inside_out'" },
|
||||
"jerk_enabled":
|
||||
{
|
||||
"enabled": false,
|
||||
"value": false
|
||||
},
|
||||
"layer_height_0": { "value": "0.2 if resolveOrValue('adhesion_type') == 'raft' else 0.3" },
|
||||
"layer_start_x": { "value": "sum(extruderValues('machine_extruder_start_pos_x')) / len(extruderValues('machine_extruder_start_pos_x'))" },
|
||||
"layer_start_y": { "value": "sum(extruderValues('machine_extruder_start_pos_y')) / len(extruderValues('machine_extruder_start_pos_y'))" },
|
||||
"machine_center_is_zero": { "default_value": true },
|
||||
"machine_depth": { "default_value": 195 },
|
||||
"machine_end_gcode": { "default_value": "; End GCode\n" },
|
||||
"machine_extruder_count": { "default_value": 1 },
|
||||
"machine_gcode_flavor": { "default_value": "Marlin" },
|
||||
"machine_heated_bed": { "default_value": true },
|
||||
"machine_height": { "default_value": 165 },
|
||||
"machine_max_feedrate_x": { "default_value": 200 },
|
||||
"machine_max_feedrate_y": { "default_value": 200 },
|
||||
"machine_max_feedrate_z": { "default_value": 25 },
|
||||
"machine_min_cool_heat_time_window": { "value": "15" },
|
||||
"machine_name": { "default_value": "MakerBot Replicator+" },
|
||||
"machine_nozzle_cool_down_speed": { "default_value": 0.8 },
|
||||
"machine_nozzle_heat_up_speed": { "default_value": 1.4 },
|
||||
"machine_start_gcode": { "default_value": "; Start GCode\n" },
|
||||
"machine_width": { "default_value": 295 },
|
||||
"material_bed_temperature": { "enabled": false },
|
||||
"material_bed_temperature_layer_0": { "enabled": false },
|
||||
"material_diameter": { "default_value": 1.75 },
|
||||
"material_final_print_temperature":
|
||||
{
|
||||
"enabled": false,
|
||||
"value": "material_print_temperature"
|
||||
},
|
||||
"material_flow": { "default_value": 100 },
|
||||
"material_initial_print_temperature":
|
||||
{
|
||||
"enabled": false,
|
||||
"value": "material_print_temperature"
|
||||
},
|
||||
"material_print_temperature":
|
||||
{
|
||||
"maximum_value": 250,
|
||||
"maximum_value_warning": 235
|
||||
},
|
||||
"material_print_temperature_layer_0":
|
||||
{
|
||||
"maximum_value": 250,
|
||||
"maximum_value_warning": 235,
|
||||
"value": "material_print_temperature + 5"
|
||||
},
|
||||
"min_bead_width":
|
||||
{
|
||||
"minimum_value": "line_width * 0.5",
|
||||
"minimum_value_warning": "line_width * 0.625",
|
||||
"value": "line_width * 0.75"
|
||||
},
|
||||
"min_wall_line_width":
|
||||
{
|
||||
"minimum_value": "line_width * 0.5",
|
||||
"minimum_value_warning": "line_width * 0.75",
|
||||
"value": "line_width"
|
||||
},
|
||||
"minimum_support_area": { "value": 0.5 },
|
||||
"multiple_mesh_overlap": { "value": "0" },
|
||||
"optimize_wall_printing_order": { "value": "True" },
|
||||
"prime_blob_enable":
|
||||
{
|
||||
"default_value": false,
|
||||
"enabled": false,
|
||||
"value": "resolveOrValue('print_sequence') != 'one_at_a_time'"
|
||||
},
|
||||
"print_sequence": { "enabled": false },
|
||||
"raft_airgap": { "value": 0.3 },
|
||||
"raft_base_flow": { "value": 120 },
|
||||
"raft_base_infill_overlap": { "value": 25 },
|
||||
"raft_base_line_spacing": { "value": 2.5 },
|
||||
"raft_base_line_width": { "value": 2 },
|
||||
"raft_base_thickness": { "value": 0.4 },
|
||||
"raft_interface_fan_speed": { "value": 0 },
|
||||
"raft_interface_infill_overlap": { "value": 25 },
|
||||
"raft_interface_wall_count": { "value": "raft_wall_count" },
|
||||
"raft_margin": { "value": 6.5 },
|
||||
"raft_surface_fan_speed": { "value": 50.0 },
|
||||
"raft_surface_infill_overlap": { "value": 35 },
|
||||
"raft_surface_wall_count": { "value": "raft_wall_count" },
|
||||
"raft_wall_count": { "value": 2 },
|
||||
"retract_at_layer_change": { "value": true },
|
||||
"retraction_amount":
|
||||
{
|
||||
"maximum_value": 5,
|
||||
"maximum_value_warning": 2.5,
|
||||
"value": 0.5
|
||||
},
|
||||
"retraction_combing": { "value": "'infill'" },
|
||||
"retraction_count_max":
|
||||
{
|
||||
"maximum_value": 700,
|
||||
"maximum_value_warning": 600,
|
||||
"value": 500
|
||||
},
|
||||
"retraction_extra_prime_amount": { "value": 0.1 },
|
||||
"retraction_min_travel": { "value": "2 * line_width" },
|
||||
"retraction_prime_speed":
|
||||
{
|
||||
"maximum_values": 35,
|
||||
"value": 30
|
||||
},
|
||||
"retraction_retract_speed":
|
||||
{
|
||||
"maximum_value": 55,
|
||||
"value": 50
|
||||
},
|
||||
"retraction_speed":
|
||||
{
|
||||
"maximum_value": 55,
|
||||
"value": 50
|
||||
},
|
||||
"roofing_material_flow": { "value": "material_flow" },
|
||||
"skin_material_flow": { "value": "material_flow" },
|
||||
"skin_material_flow_layer_0": { "value": "material_flow" },
|
||||
"skirt_brim_line_width": { "value": 0.8 },
|
||||
"skirt_brim_minimal_length": { "value": 150 },
|
||||
"skirt_brim_speed": { "value": 15 },
|
||||
"skirt_height": { "value": 3 },
|
||||
"speed_equalize_flow_width_factor": { "value": 100 },
|
||||
"speed_print": { "value": 90 },
|
||||
"speed_roofing": { "value": "1 * speed_print" },
|
||||
"speed_support": { "value": "1 * speed_print" },
|
||||
"speed_support_interface": { "value": "speed_support" },
|
||||
"speed_topbottom": { "value": "speed_roofing" },
|
||||
"speed_travel": { "value": 150 },
|
||||
"speed_wall": { "value": "1 * speed_print" },
|
||||
"speed_wall_0": { "value": "4/9 * speed_wall" },
|
||||
"speed_wall_x": { "value": "1 * speed_wall" },
|
||||
"speed_z_hop": { "value": 10 },
|
||||
"support_angle": { "value": 68 },
|
||||
"support_bottom_enable": { "value": false },
|
||||
"support_brim_enable": { "value": false },
|
||||
"support_connect_zigzags": { "value": false },
|
||||
"support_infill_angles": { "value": "[45]" },
|
||||
"support_infill_rate": { "value": 20 },
|
||||
"support_interface_density": { "value": 90 },
|
||||
"support_interface_enable": { "value": true },
|
||||
"support_interface_height": { "value": 0.8 },
|
||||
"support_interface_wall_count": { "value": 0 },
|
||||
"support_line_width": { "value": 0.35 },
|
||||
"support_material_flow": { "value": 90 },
|
||||
"support_offset": { "value": 1 },
|
||||
"support_structure": { "value": "'normal'" },
|
||||
"support_use_towers": { "value": false },
|
||||
"support_xy_distance": { "value": 0.3 },
|
||||
"support_z_distance": { "value": 0.2 },
|
||||
"top_bottom_thickness": { "value": "4 * layer_height" },
|
||||
"travel_avoid_distance": { "value": 2 },
|
||||
"travel_avoid_supports": { "value": true },
|
||||
"wall_0_inset": { "value": "0" },
|
||||
"wall_0_material_flow_layer_0": { "value": "material_flow" },
|
||||
"wall_thickness": { "value": "2 * machine_nozzle_size" },
|
||||
"wall_x_material_flow": { "value": "material_flow" },
|
||||
"wall_x_material_flow_layer_0": { "value": "1 * material_flow" },
|
||||
"xy_offset": { "value": 0 },
|
||||
"xy_offset_layer_0": { "value": 0 },
|
||||
"z_seam_corner": { "value": "'z_seam_corner_any'" },
|
||||
"zig_zaggify_infill": { "value": "gradual_infill_steps == 0" }
|
||||
}
|
||||
}
|
||||
|
|
@ -273,6 +273,11 @@
|
|||
"skin_material_flow": { "value": 95 },
|
||||
"skin_overlap": { "value": 0 },
|
||||
"skin_preshrink": { "value": 0 },
|
||||
"skirt_brim_speed":
|
||||
{
|
||||
"maximum_value_warning": 300,
|
||||
"value": "speed_layer_0"
|
||||
},
|
||||
"skirt_line_count": { "value": 5 },
|
||||
"small_skin_on_surface": { "value": false },
|
||||
"small_skin_width": { "value": 4 },
|
||||
|
|
@ -311,11 +316,6 @@
|
|||
"maximum_value_warning": 300,
|
||||
"value": "speed_wall"
|
||||
},
|
||||
"speed_skirt_brim":
|
||||
{
|
||||
"maximum_value_warning": 300,
|
||||
"value": "speed_layer_0"
|
||||
},
|
||||
"speed_support":
|
||||
{
|
||||
"maximum_value_warning": 300,
|
||||
|
|
@ -382,7 +382,6 @@
|
|||
"value": "speed_wall"
|
||||
},
|
||||
"support_brim_line_count": { "value": 5 },
|
||||
"support_density": { "value": "15 if support_structure == 'tree' else 20" },
|
||||
"support_infill_rate": { "value": "80 if gradual_support_infill_steps != 0 else 15" },
|
||||
"support_interface_enable": { "value": true },
|
||||
"support_pattern": { "value": "'gyroid' if support_structure == 'tree' else 'lines'" },
|
||||
|
|
|
|||
|
|
@ -58,7 +58,9 @@
|
|||
"ultimaker_rapidrinse",
|
||||
"ultimaker_sr30",
|
||||
"ultimaker_petg",
|
||||
"ultimaker_pva"
|
||||
"ultimaker_pva",
|
||||
"ultimaker_pc-abs",
|
||||
"ultimaker_pc-abs-fr"
|
||||
],
|
||||
"has_machine_quality": true,
|
||||
"has_materials": true,
|
||||
|
|
|
|||
|
|
@ -53,7 +53,9 @@
|
|||
"ultimaker_pva",
|
||||
"ultimaker_rapidrinse",
|
||||
"ultimaker_sr30",
|
||||
"ultimaker_petg"
|
||||
"ultimaker_petg",
|
||||
"ultimaker_pc-abs",
|
||||
"ultimaker_pc-abs-fr"
|
||||
],
|
||||
"has_machine_quality": true,
|
||||
"has_materials": true,
|
||||
|
|
|
|||
22
resources/extruders/ultimaker_replicator_extruder.def.json
Normal file
22
resources/extruders/ultimaker_replicator_extruder.def.json
Normal file
|
|
@ -0,0 +1,22 @@
|
|||
{
|
||||
"version": 2,
|
||||
"name": "Extruder",
|
||||
"inherits": "fdmextruder",
|
||||
"metadata":
|
||||
{
|
||||
"machine": "ultimaker_replicator_plus",
|
||||
"position": "0"
|
||||
},
|
||||
"overrides":
|
||||
{
|
||||
"extruder_nr":
|
||||
{
|
||||
"default_value": 0,
|
||||
"maximum_value": 0
|
||||
},
|
||||
"machine_nozzle_offset_x": { "default_value": 0 },
|
||||
"machine_nozzle_offset_y": { "default_value": 0 },
|
||||
"machine_nozzle_size": { "default_value": 0.4 },
|
||||
"material_diameter": { "default_value": 1.75 }
|
||||
}
|
||||
}
|
||||
Binary file not shown.
|
Before
(image error) Size: 6.9 KiB After
(image error) Size: 24 KiB
|
Binary file not shown.
|
Before
(image error) Size: 12 KiB After
(image error) Size: 15 KiB
|
Binary file not shown.
|
Before
(image error) Size: 3.7 KiB After
(image error) Size: 13 KiB
|
Binary file not shown.
|
Before
(image error) Size: 3.9 KiB After
(image error) Size: 14 KiB
|
Binary file not shown.
|
Before
(image error) Size: 10 KiB After
(image error) Size: 14 KiB
|
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = 1C
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = 1C
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = 1XA
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = 1XA
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = LABS
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = LABS
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = 1C
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = 1C
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = 1XA
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = 1XA
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = LABS
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,22 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Solid
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = solid
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = LABS
|
||||
|
||||
[values]
|
||||
bottom_thickness = =top_bottom_thickness
|
||||
infill_angles = [45,135]
|
||||
infill_material_flow = 97
|
||||
infill_pattern = zigzag
|
||||
infill_sparse_density = 99
|
||||
top_bottom_thickness = =layer_height * 2
|
||||
top_thickness = =top_bottom_thickness
|
||||
|
||||
|
|
@ -0,0 +1,18 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Quick
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
intent_category = quick
|
||||
material = ultimaker_pla_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = intent
|
||||
variant = Smart Extruder+
|
||||
|
||||
[values]
|
||||
jerk_print = 30
|
||||
speed_wall = =speed_print
|
||||
speed_wall_0 = =speed_wall
|
||||
|
||||
BIN
resources/meshes/ultimaker_replicator_plus_platform.3MF
Normal file
BIN
resources/meshes/ultimaker_replicator_plus_platform.3MF
Normal file
Binary file not shown.
|
|
@ -166,8 +166,8 @@ Button
|
|||
}
|
||||
|
||||
mismatchedCores = "<b>" + mismatchedCores + "</b>"
|
||||
var draftResult = catalog.i18nc("@label", "This configuration is not available because there is a mismatch or other problem with core-type %1. Please visit %2 to check which cores this printer-type supports w.r.t. new slices.");
|
||||
return draftResult.arg(mismatchedCores).arg("<a href=' '>" + catalog.i18nc("@label","WEBSITE") + "</a> ")
|
||||
var draftResult = catalog.i18nc("@label", "This configuration is not available because there is a mismatch or other problem with core-type %1. Please visit <a href='%2'>the support page</a> to check which cores this printer-type supports w.r.t. new slices.");
|
||||
return draftResult.arg(mismatchedCores).arg("https://support.ultimaker.com/s/article/1667411313529")
|
||||
}
|
||||
|
||||
text:
|
||||
|
|
@ -199,9 +199,16 @@ Button
|
|||
|
||||
wrapMode: Text.WordWrap
|
||||
|
||||
onLinkActivated:
|
||||
onLinkActivated: (link) =>
|
||||
{
|
||||
Cura.Actions.browsePackages.trigger()
|
||||
if(link.trim().length === 0)
|
||||
{
|
||||
Cura.Actions.browsePackages.trigger();
|
||||
}
|
||||
else
|
||||
{
|
||||
Qt.openUrlExternally(link);
|
||||
}
|
||||
}
|
||||
}
|
||||
|
||||
|
|
|
|||
|
|
@ -0,0 +1,66 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = 1C
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_base_thickness = =0.6 if extruder_nr == support_extruder_nr else 0.8
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 5/6
|
||||
speed_support_bottom = 25
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_width = 0.6
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,67 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = 1C
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_base_thickness = =0.6 if extruder_nr == support_extruder_nr else 0.8
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 1/2
|
||||
speed_support_bottom = =speed_support * 1/4
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_distance = =support_line_distance
|
||||
support_bottom_line_width = 0.8
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,66 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = 1XA
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_base_thickness = =0.6 if extruder_nr == support_extruder_nr else 0.8
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 5/6
|
||||
speed_support_bottom = 25
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_width = 0.6
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,67 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = 1XA
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_base_thickness = =0.6 if extruder_nr == support_extruder_nr else 0.8
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 1/2
|
||||
speed_support_bottom = =speed_support * 1/4
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_distance = =support_line_distance
|
||||
support_bottom_line_width = 0.8
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,66 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = LABS
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_base_thickness = =0.6 if extruder_nr == support_extruder_nr else 0.8
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 5/6
|
||||
speed_support_bottom = 25
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_width = 0.6
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,67 @@
|
|||
[general]
|
||||
definition = ultimaker_methodx
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = LABS
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_base_thickness = =0.6 if extruder_nr == support_extruder_nr else 0.8
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 1/2
|
||||
speed_support_bottom = =speed_support * 1/4
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_distance = =support_line_distance
|
||||
support_bottom_line_width = 0.8
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,65 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = 1C
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 5/6
|
||||
speed_support_bottom = 25
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_width = 0.6
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,66 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = 1C
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 1/2
|
||||
speed_support_bottom = =speed_support * 1/4
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_distance = =support_line_distance
|
||||
support_bottom_line_width = 0.8
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,65 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = 1XA
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 5/6
|
||||
speed_support_bottom = 25
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_width = 0.6
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,66 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = 1XA
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 1/2
|
||||
speed_support_bottom = =speed_support * 1/4
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_distance = =support_line_distance
|
||||
support_bottom_line_width = 0.8
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,65 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = LABS
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 5/6
|
||||
speed_support_bottom = 25
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_width = 0.6
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,66 @@
|
|||
[general]
|
||||
definition = ultimaker_methodxl
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pc-abs-fr_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = LABS
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
cool_fan_enabled = =extruder_nr == support_extruder_nr
|
||||
cool_fan_speed_0 = 0
|
||||
cool_fan_speed_max = 80
|
||||
cool_min_layer_time = 10
|
||||
cool_min_layer_time_fan_speed_max = 8
|
||||
cool_min_speed = =round(speed_wall_0 * 3 / 4) if cool_lift_head else round(speed_wall_0 / 5)
|
||||
cool_min_temperature = 250
|
||||
infill_sparse_density = 15
|
||||
material_final_print_temperature = =material_print_temperature - 5
|
||||
material_initial_print_temperature = =material_print_temperature - 5
|
||||
raft_airgap = =0.1 if extruder_nr == support_extruder_nr else 0
|
||||
raft_base_infill_overlap = 20
|
||||
raft_surface_speed = =speed_print * 3/4 if extruder_nr == support_extruder_nr else 50
|
||||
skin_overlap = 10
|
||||
speed_layer_0 = =speed_print * 7/24
|
||||
speed_prime_tower = =speed_print * 1/4
|
||||
speed_print = 120.0
|
||||
speed_roofing = =speed_print * 13/24
|
||||
speed_support = =speed_print * 1/2
|
||||
speed_support_bottom = =speed_support * 1/4
|
||||
speed_support_interface = =speed_print * 15/24
|
||||
speed_topbottom = =speed_print * 11/24
|
||||
speed_wall = =speed_print * 5/24
|
||||
speed_wall_0 = =speed_print * 1/6
|
||||
support_angle = 50
|
||||
support_bottom_angles = [135]
|
||||
support_bottom_density = 15
|
||||
support_bottom_distance = 0.1
|
||||
support_bottom_enable = True
|
||||
support_bottom_line_distance = =support_line_distance
|
||||
support_bottom_line_width = 0.8
|
||||
support_bottom_stair_step_height = 0
|
||||
support_infill_angles = [45,45,45,45,45,45,45,45,45,45,135,135,135,135,135,135,135,135,135,135]
|
||||
support_infill_rate = 15.0
|
||||
support_interface_density = 85
|
||||
support_interface_enable = True
|
||||
support_interface_pattern = zigzag
|
||||
support_line_width = 0.3
|
||||
support_material_flow = 100
|
||||
support_pattern = zigzag
|
||||
support_roof_density = 85
|
||||
support_roof_wall_count = 1
|
||||
support_supported_skin_fan_speed = 60.0
|
||||
support_top_distance = =support_z_distance
|
||||
support_xy_distance = 0.35
|
||||
support_xy_distance_overhang = 0.25
|
||||
support_xy_overrides_z = xy_overrides_z
|
||||
support_z_distance = 0.203
|
||||
top_skin_expand_distance = 2.4
|
||||
wall_overhang_angle = 30
|
||||
wall_overhang_speed_factor = 40
|
||||
|
||||
|
|
@ -0,0 +1,16 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Fast - Experimental
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
is_experimental = True
|
||||
material = ultimaker_pla_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = Smart Extruder+ Experimental
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
|
||||
|
|
@ -0,0 +1,16 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Fast - Experimental
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
is_experimental = True
|
||||
material = ultimaker_tough_pla_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = Smart Extruder+ Experimental
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
|
||||
|
|
@ -0,0 +1,15 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_tough_pla_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = Smart Extruder+ Tough
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
|
||||
|
|
@ -0,0 +1,15 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
material = ultimaker_pla_175
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
variant = Smart Extruder+
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
|
||||
|
|
@ -0,0 +1,15 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Fast
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
global_quality = True
|
||||
quality_type = draft
|
||||
setting_version = 24
|
||||
type = quality
|
||||
weight = -2
|
||||
|
||||
[values]
|
||||
layer_height = 0.2
|
||||
|
||||
|
|
@ -18,6 +18,7 @@
|
|||
"UltiMaker Method": "ultimaker_method",
|
||||
"UltiMaker Method X": "ultimaker_methodx",
|
||||
"UltiMaker Method XL": "ultimaker_methodxl",
|
||||
"UltiMaker Replicator+": "ultimaker_replicator_plus",
|
||||
"UltiMaker Sketch": "ultimaker_sketch",
|
||||
"UltiMaker Sketch Large": "ultimaker_sketch_large"
|
||||
}
|
||||
|
|
@ -0,0 +1,15 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Smart Extruder+
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
hardware_type = nozzle
|
||||
reference_extruder_id = mk13
|
||||
setting_version = 24
|
||||
type = variant
|
||||
|
||||
[values]
|
||||
machine_nozzle_id = Smart Extruder+
|
||||
machine_nozzle_size = 0.4
|
||||
|
||||
|
|
@ -0,0 +1,15 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Smart Extruder+ Tough
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
hardware_type = nozzle
|
||||
reference_extruder_id = mk13_im-pla
|
||||
setting_version = 24
|
||||
type = variant
|
||||
|
||||
[values]
|
||||
machine_nozzle_id = Smart Extruder+ Tough
|
||||
machine_nozzle_size = 0.4
|
||||
|
||||
|
|
@ -0,0 +1,15 @@
|
|||
[general]
|
||||
definition = ultimaker_replicator_plus
|
||||
name = Smart Extruder+ Experimental
|
||||
version = 4
|
||||
|
||||
[metadata]
|
||||
hardware_type = nozzle
|
||||
reference_extruder_id = mk13_experimental
|
||||
setting_version = 24
|
||||
type = variant
|
||||
|
||||
[values]
|
||||
machine_nozzle_id = Smart Extruder+ Experimental
|
||||
machine_nozzle_size = 0.4
|
||||
|
||||
Loading…
Add table
Add a link
Reference in a new issue
